FOLDER GLUER T-Folder 2000
Double Feeder Double Piece Folder Gluer
T-Folder 2000 robust multifunctional double feeding and pasting machine.
Composition
- Double feeder section
- Side folding device
- Front lay alignment section
- Transfer section
Specifications
Parameters
Value
Cardboard:
300 g to 800 g
Corrugated type::
A ,B, C, E, K, BC, EB, AB
Max. speed:
250 m/min
Inching speed:
10 m/min
Cardboard thickness:
<10 mm
Blank width:
650 to 2000 mm
-piece box open blank max. width:
4000 mm
Glue type
Hotmelt & cold glue
Dimensions:
9.91 x 4 x 2 m
Weight:
7 ton
Power supply:
50 kW
Compressed air:
10 bar
Capacity:
150 L
